Aircraft wing explained part.2
..................... After we discovered how the shape of the wing's airfoil created lift force which were based on Bernoulli's principle and how to make use of it , now we take the next step of analyzing how the shape and structure of the wing itself contributed on the performance of the aircraft, in which how the aerodynamic advantages and dis-advantages of each of the following shape and structure. PART.2 "THE SHAPE" W hen we talk about the aircraft wings shape, we are actually talking about the model of the wind flows that flows around it. As we know that to be an effective lift force, the wings must produce enough pressure on the underneath and smoother flow at the top of the wings, this however only focuses on the wings cutaway structure in a one sided point of view, this second part however will focuses on the stream flowing around the wings at the top point of view on an aircraft. To make it clear let me show you an example of top viewed...
